| Size | Thread Size 'C' MM | Minimum Length of Thread 'D' | Cable Range 'A' | |
| Max | Min | |||
| A2 20S | 20 | 15 | 10.80 | 8.80 |
| A2 20L | 20 | 15 | 14.70 | 11.40 |
| A2 25S | 25 | 15 | 16.00 | 13.00 |
| A2 25L | 25 | 15 | 20.30 | 17.30 |
| A2 32S | 32 | 15 | 23.00 | 20.00 |
| A2 32L | 32 | 15 | 26.20 | 24.20 |
| A2 40S | 40 | 20 | 29.00 | 26.00 |
| A2 40L | 40 | 20 | 34.00 | 29.50 |
| A2 50S | 50 | 20 | 41.00 | 33.00 |
| A2 50L | 50 | 20 | 45.00 | 38.00 |
| A2 63S | 63 | 20 | 51.50 | 44.00 |
| A2 63L | 63 | 20 | 56.50 | 50.00 |
| A2 75S | 75 | 20 | 63.20 | 56.00 |
| A2 75L | 75 | 20 | 68.50 | 62.00 |
Materials:
- Brass BS 2874
- Brass CZ 121 Pb 3
- Any special brass material composition as per customer’s requirements.
Finish /Plating:
- Brass Natural
- Nickel Plated
- Any special plating as per customer’s specification.
Application:
- Outdoor or Indoor for use with all types of unarmored cables
Function:
- Provide seal on outer sheath of the unarmored cables.
Optional Threads:
- Metrics Threads
- NPT Threads
- BSP Threads
- Any special threads as per customer’s specifications.
Operation Temp:
- Standard seals -20* C To +80*C
Accessories:
- Matching Accessories available like PVC surrounds Lock Nuts, Earth Tags, and Reducers Adaptors etc.As per customer’s specifications.
